GASO T165 Triplex Piston Pump

Wheatley Pump is an OEM supplier of the Gaso T165 Pump. The team at IEQ Industries is here to keep your pumps running strong.

Providing Industry Solutions for 90 Years

PSI

5,115 PSI (max)

BPH

370BPH (max)

GPM

301.9 GPM (max)

Download your copy of the T165 Specs.
Gaso T165 Triplex Piston Pump

Specifications

Pump Size:

Stroke length, 5″

Rated Plunger Load

10200 pounds

Crank Pin

Diameter, in.: 3
Width, in.: 5.5

Crank Shaft

Diameter, 4.160″
Keyway width x depth, in.: 1 x 1/2

Oil Capacity: gallons (L)

11 gallons

Weight, pump only on wood shipping skids, pounds (kg):

3800 LBM

Standard Materials for Fluid End Bodies:

T165-2
- CAST Nickel-Aluminum-Bronze
- CAST Carbon Steel
- CAST Duplex Stainless Steel
- BILLET Carbon Steel
T165-3
- CAST Nickel-Aluminum-Bronze
- CAST Carbon Steel
- CAST Duplex Stainless Steel
- BILLET Carbon Steel
T165-4
- CAST Ductile Iron
- CAST Nickel-Aluminum-Bronze
- CAST Carbon Steel
- CAST Duplex Stainless Steel

Performance Chart

Gaso T165 English Chart

PUMP	English Units	100 RPM	190 RPM	280 RPM	370 RPM
Plunger Dia. In.	GPM per RPM	Max. Press. PSI	BPD	GPM	BPD	GPM	BPD	GPM	BPD	GPM
T165-2	1.5	0.1148	5115	394	11.5	748	21.8	1102	32.1	1456	42.5
1.625	0.1347	4920	462	13.5	811	25.6	1293	37.7	1709	49.8
1.75	0.1562	4240	536	15.6	1018	29.7	1500	43.7	1982	57.8
1.875	0.1793	3695	615	17.9	1168	34.1	1721	50.2	2275	66.3
2	0.204	3245	699	20.4	1329	38.8	1958	57.1	2588	75.5
T165-3	2	0.204	3245	699	20.4	1329	38.8	1958	57.1	2588	75.5
2.125	0.2303	2875	790	23	1500	43.8	2211	64.5	2922	85.2
2.25	0.2582	2565	885	25.8	1682	49.1	3275	72.3	2479	95.5
2.375	0.2877	2300	986	28.8	1874	54.7	2762	80.6	3650	106.4
2.5	0.3187	2075	1093	31.9	2076	60.6	3060	89.2	4043	117.9
2.625	0.3514	1885	1205	35.1	2289	66.8	3373	98.4	4458	130
2.75	0.3857	1715	1322	38.6	2513	73.3	3703	108	4893	142.7
T165-4	2.75	0.3857	1715	1322	38.6	2513	73.3	3703	108	4893	142.7
3	0.459	1445	1574	45.9	2990	87.2	4406	128.5	5823	169.8
3.25	0.5387	1230	1847	53.9	3509	102.4	5172	150.8	6834	199.3
3.5	0.6247	1060	2142	62.5	4069	118.7	5997	174.9	7925	231.1
3.75	0.7172	925	2459	71.7	4672	136.3	6885	200.8	9098	265.4
4	0.816	810	2798	81.6	5316	155	7834	228.5	10352	301.9
	Brake Horsepower Required	43	82	120	159
